LEN Performance Rear shock Lynx Ranger / Xterrain / Shredder / Boondocker 600-900 20-25

The main shock absorber located at the rear of the snowmobile chassis. It is responsible for absorbing shocks when driving on uneven surfaces and for stability when cornering.

Dimensions:

• Weight: 4.65 kg.
• Length (fully extended): 550 mm.
• Length (fully compressed): 393 mm.
• Travel: 157 mm.
• Upper mounting eye inner diameter: 10 mm.
• Upper mounting eye width: 25.4 mm (1 inch).
• Lower mounting eye inner diameter: 10 mm.
• Lower mounting eye width: 25.4 mm (1 inch).
• Spring diameter: 72 mm.
• Compression adjustment: 5-step adjustment.
• Rebound adjustment: 5-step adjustment.

Fits:

LYNX 49 RANGER 600 ACE  STD 2020-22
LYNX 49 RANGER 600R ETEC  PRO 2020-22
LYNX 49 RANGER 900 ACE 2020-21
LYNX 49 RANGER 900 ACE  PRO 2021-22
LYNX 49 RANGER PRO 600R E-TEC 2023-25
LYNX 49 RANGER PRO 850 E-TEC 2024-25
LYNX 49 RANGER PRO  600R ETEC 2023
LYNX 49 RANGER ST - 900 ACE TURBO 2023-24
LYNX 49 RANGER ST 900 ACE 2023-24
LYNX 49 RANGER STD 600 ACE 2023-25
LYNX BOONDOCKER 3900 600R ETEC 2020-22
LYNX BOONDOCKER DS 850 E-TEC 3900 2022
LYNX BOONDOCKER DS 850 E-TEC 4100 2022
LYNX SHREDDER 600R ETEC 146 2023-25
LYNX SHREDDER 600R ETEC 154 2024-25
LYNX SHREDDER DS 3900 850 ETEC 2023
LYNX SHREDDER DS 3900 850 E-TEC TURBO R 2023-24
LYNX SHREDDER RE 3700 850 ETEC 2023-24
LYNX SHREDDER RE 3700 850 ETEC TURBO R 2024
LYNX SHREDDER RE 3900 850 ETEC 2023-24
LYNX SHREDDER RE 3900 850 ETEC TURBO R 2023-24
LYNX XTERRAIN 3700 600 EFI 2021-24
LYNX XTERRAIN 3700 600R ETEC 2021-24
LYNX XTERRAIN 3900 600R ETEC 2021
LYNX XTERRAIN 600 EFI 146 2024
LYNX XTERRAIN 600R ETEC 146 2024
LYNX XTERRAIN PRO 3900 600R ETEC 2021-23
LYNX XTERRAIN PRO 3900 850 ETEC 2021-23
LYNX XTERRAIN STD 3700  600 EFI 2022-23
LYNX XTERRAIN STD 3700  600R ETEC 2022-23
LYNX XTERRAIN STD 3900  600 EFI 2022-23
LYNX XTERRAIN STD 3900  600R ETEC 2022-23
