Arher Spindle assembly Ø68mm Murray

This is the main assembly of the cutting deck, inside which the axis rotates. A pulley is placed on the upper part, and a cutting blade is screwed to the lower part. The kit consists of a housing, bearings and an axis. It is fully assembled and ready for installation.

Dimensions:

• Housing at the central part 68 mm.
• Distance between the fixing points 147 mm.
• 9.5 mm thread.

Fits:

Murray:
38702x20C, 38608x20D, 38608x20C, 38608x20A,
38501x50A, 38501x50B, 38501x50C, 38501x50D

OEM:

Murray 492574MA
Murray ray 690488
Murray 92574
Murray 90905
Murray 24384
Murray 20551
19-905
